Description
Battery type
CR-P2 (6 V)
Protection class
IP65
Operating voltage
6 V DC
Operating pressure
100-850 kPa
Test pressure water max.
1600 kPa
Test pressure air / inert gas max.
300 kPa
Water temperature max.
65 °C
Water temperature short term max.
80 °C
Flow rate at 3 bar
5.7 l/min
Minimum flow pressure for calculation flow rate
50 kPa
Calculation flow rate
0.07 l/s
Interval flushing
24 h
Interval flushing time
10 s
Material
brass
Click on an application to search for other products
For drawing tap water
For children
For childcare facilities
For installation in washbasins or washbasin tops
For installation in Bambini play and wash landscapes
For connecting cold and hot water
For combination with instantaneous water heaters, see technical data sheet "Washbasin taps with instantaneous water heaters"
Click on a feature to search for other products
Child-friendly design
Faucet group I according to DIN 4109
Automatic flush release
Infrared user detection
Self-adjusting IR sensor
Flow rate limitation by aerator
Power supply via battery
Battery sufficient for approx. 200,000 activations
Low battery warning
Water saving due to fast-reacting dual jet scanning technology
Adjustable activation distance
Interval flushing
Flush activation for basin cleaning can be deactivated manually
With integrated backflow preventer
Chrome-plated housing
Polycarbonate cap
Battery compartment
Lithium battery type CR-P2 6 V
Basket filter
Key for aerator
Mounting material
Colour / finish: Hat: dust grey Body: bright chrome-plated
Mixer: with mixer
W: 8 cm
H: 12.6 cm
D: 12.4 cm
PU1: 1 pc.
