Line noise at 3 bar
15 dB(A)
Sound class
1
Inlet capacity at 3 bar
0.35 l/s
Discharge rate
0.85 l/s
Overflow discharge rate
0.6 l/s
Depth of water seal
50 mm
For bathtubs with valve hole ø 52 mm
For bathtubs made of steel, plastic or cast iron
For custom-size bathtubs
With overflow and inlet
Quality-monitored in accordance with EN 274-3
Inlet jet can be aligned
Double-sided seals on drain and overflow
Overflow head with extendible mount can be fastened
Overflow head with inlet
Waste outlet
Trap
Elbow tap connector 90° with MasterFix, 1/2", radial-sealing
Connection bend made of PE-HD, ø 40 / 50 mm
Protection box
Fastening material
Ready-to-fit set
DN: 40
d, ø: 40/50 mm
