Operating temperature
-20 – +95 °C
Product material
CrNiMo steel 1.4401 (EN 10088)
Click on an application purpose to search more products
For cold and hot potable water
For cooling and heating water without antifreeze agent
For cooling and heating water with antifreeze agent
For treated water (application range according to Technical Information „Treated water“)
For rainwater with a pH value of > 6.0
For compressed air (oil purity class 0–3)
For negative pressure
For inert gases (e.g. nitrogen)
Click on a characteristic to search more products
Approval in accordance with DVGW
Model Geberit T4
Ball and base unit fully exposed to flow
Lever fastening with screw
Replaceable upper part
Ball made of PPSU
Upper part caulk made of EPDM
Ball caulks made of silicone
Pressing indicator
Leaky if unpressed
Seal ring made of CIIR, black
Pressing socket with transparent protection plug
Colour markings (red, blue, green)
DN: 50
DNV: 50
d, ø: 54 mm
L: 20.6 cm
L1: 9 cm
L2: 14.7 cm
Z: 6.8 cm
PN: 16 bar
