Description
Head of water max.
50 mm
Click on an application purpose to search more products
For collecting and draining off rainwater from roofs
For syphonic roof drainage systems
For connecting bituminous roof sealings
Click on a characteristic to search more products
Vertical outlet
Straight connector can be reduced directly or extended
Straight connector made of PE-HD, can be shortened
Outlet grating with function disc
Base unit with contact sheet made of CrNi steel 1.4301
Protection box cover
Anticondensation insulation
DN: 90
Sealing of connection: CrNi steel 1.4301
d, ø: 90 mm
Discharge rate: 1–25 l/s
