Head of water max.
50 mm
Click on an application purpose to search more products
For collecting and draining off rainwater from roofs
For gutters with a minimum width of 30 cm
For connecting metallic product materials
For syphonic roof drainage systems
Click on a characteristic to search more products
Vertical outlet
Straight connector can be reduced directly or extended
Straight connector made of PE-HD, can be shortened
Outlet grating with function disc
Base unit with contact sheet made of CrNi steel 1.4301
Anticondensation insulation
DN: 90
Sealing of connection: CrNi steel 1.4301
d, ø: 90 mm
Discharge rate: 1–25 l/s
