Description
Protection class
IP44
Rated voltage
230 V AC
Mains frequency
50-60 Hz
Operating voltage
12 V AC
Cable length
1.9 m
Operating pressure
50-800 kPa
Test pressure water max.
1600 kPa
Test pressure air / inert gas max.
300 kPa
Ambient temperature
1-40 °C
Water temperature max.
60 °C
Water temperature short term max.
90 °C
Flow rate at 3 bar
6 l/min
Minimum flow pressure for calculated flow rate
50 kPa
Calculation flow rate
0.07 l/s
Activation distance Setting range
5-33 cm
Activation distance Factory setting
16-18 cm
Interval flush Setting range
1-168 h
Interval flush Factory setting
168 h
Interval flush time Setting range
3-180 s
Interval flush time Factory setting
3 s
Material
Chrome-plated brass
Click on an application to search for other products
For installation in washbasins or washbasin tops
For connecting cold and hot water (only for model with mixer)
For connecting cold or mixed water (only for model without mixer)
For use with stainless steel basins
Model without mixer suitable for combination with instantaneous water heater, see technical data sheet "Washbasin taps with instantaneous water heaters"
Click on a property to search for other products
Faucet group I according to DIN 4109
Automatic flush release
Self-adjusting IR sensor
Flow rate limitation by aerator
Temperature setting via mixer (only for model with mixer)
Power supply via mains adapter
Can be converted to battery operation
Adjustable energy-saving mode
Water saving thanks to fast-reacting dual-jet sampling technology
Adjustable water-saving programme
Continuous flush individually adjustable
Functions can be set and queried with Geberit service mobile phone
Flush release can be deactivated
With integrated backflow preventer
Compatible with Geberit Control app
Basket filter
Plug-in power supply unit
Key for aerator
Fastening material
Colour / surface: high-gloss chrome-plated
Mixer: with mixer and handle
H: 16 cm
Power consumption: 0.1 W
PU1: 1 pc.
