Battery type Alkaline (1.5 V AA) Service life of supplied battery 2 years Protection class IPX4 Operating voltage 3 V DC Flow pressure 100-800 kPa Test pressure water max. 1600 kPa Water temperature max. 30 °C Flow rate at 1 kPa with flow limiter 0.18 l/s Minimum flow pressure for calculation flow rate 100 kPa Calculation flow rate 0.23 l/s Interval flushing Setting range 1-168 h Interval flush Factory setting 24 h Interval flush time Setting range 3-180 s Interval flush time Factory setting 5 s Dwell time Setting range 3-15 s Dwell time Factory setting 7 s Flush time Setting range 1-15 s Flush time Factory setting 7 s Material Brass / plastic Click on an application to search for other products For automatically flushing urinals For concealed flush actuation of urinals For installation behind the ceramic For urinal installations with inlet from the rear and outlet to the rear For Geberit installation elements for urinals, for integrated urinal flush controls or concealed surface-mounted urinal flush controls Click on a property to search for other products Compatible with Geberit Control App Device settings and operation with mobile device via integrated Bluetooth® interface Function statistics can be called up via Geberit Control App Power supply via battery Control with LED display Battery charge status can be called up via the Geberit Control app Adjustable flush time Interval flush adjustable Dynamic flush time adjustment Adjustable water-saving hybrid mode Vandal-proof Low battery warning Valve closure function when battery is empty Brightness sensor for deactivating the control unit when the urinal is dismantled Control electronics Urinal odour trap with sensor Water line with solenoid valve 2 alkaline manganese batteries type AA 1.5 V Power consumption: ≤ 0.5 W PU1: 1 pc.
