Protection degree IPX4 Nominal voltage 110–240 V AC Operating voltage 6.6 V DC Mains frequency 50–60 Hz Flow pressure 1–8 bar Test pressure, water max. 16 bar Operating temperature, water max. 30 °C Flow rate at 1 bar with flow limiter 0.18 l/s Minimum flow pressure 1 bar Calculated flow rate 0.23 l/s Interval flush, adjustment range 1–168 h Interval flush, factory setting 24 h Interval flush time, adjustment range 3–180 s Interval flush time, factory setting 5 s Detection time, adjustment range 3–15 s Detection time, factory setting 7 s Flush time, adjustment range 1–15 s Flush time, factory setting 7 s Product material Brass / plastic Click on an application purpose to search more products For automatic flush actuation of urinals For hidden flush actuation of urinals For installation behind the ceramic appliance For urinal installations with inlet from the rear and outlet to the rear For Geberit installation elements for urinal, for integrated urinal flush control or hidden exposed urinal flush control Click on a characteristic to search more products Power supply via mains connection Integrated power supply unit with LED display Control with LED display Device settings and operation with mobile device via integrated Bluetooth® interface Compatible with Geberit Control App Function statistics available via Geberit Control App Flush time can be set Adjustable interval flush Dynamic flushing time adjustment Water-saving hybrid mode can be set Ready for operation upon connection to mains One-time flush after activation of the power supply Vandal-resistant Power failure control unit Valve-closing function when power fails Brightness sensor to deactivate the control when urinal is removed Control electronics Urinal trap with sensor Water section with solenoid valve Power consumption: ≤ 0.5 W
