Main features
Cistern GD 2, 6-9 litres
1.20 m height
For pre-wall or stud wall installation
Steel frame
Completely pre-assembled
Fixed object connections
With quick adjustment and height lock
fixing material
TÜV-tested
2 WC retaining bolts
Ceramic fixing
Screw spacing 180/230 mm
PP drain bend Ø 80 mm
depth adjustable
Reducer Ø 80/100 mm
Inlet and outlet fitting
Pneumatic drain valve with two functions: 2 volumes or start & stop
Water connection from left/right/rear or top
Fittings group I
Insulated against condensation
1/2" water connection with integrated angle valve and tool-free hose screw connection
Shortenable inspection shaft with pipework protection
Without accessories for pre-wall installation
without cover plate/actuator
GROHE Water Saving - less water, perfect water flow
