Features
Connection
Internal thread
Concealed parts
Gasket sleeve for dry mortarless construction, Mounting box and cover sleeve, Multifix fastening system
Mechanical parts
Pressure plug
Advanced features
Inner body made of DZR brass
Technical properties
Connection size
G1/2
DN-size (nominal dimension)
DN15
Hot water supply
max. +80°C
Material
Brass
Working pressure
1 - 10 bar
Sustainability
EPD module A1 (kg CO2 eq.)
7,81
EPD module A1-A3 (kg CO2 eq.)
8,91
EPD module A2 (kg CO2 eq.)
0,35
EPD module A3 (kg CO2 eq.)
0,74
EPD module A4 (kg CO2 eq.)
0,19
EPD module C2 (kg CO2 eq.)
0,02
EPD module C3 (kg CO2 eq.)
0,02
EPD module C4 (kg CO2 eq.)
0,27
EPD module D (kg CO2 eq.)
-6,42
