Features
Aerator
Laminar stream, Standard aerator
Connection
Copper inlet pipes
Lever/Handle
Hot/Cold symbols, Single operating lever/handle
Mechanical parts
ø 48 mm ceramic eco cartridge for flow and temperature control
Advanced features
Inner body made of DZR brass, Rapid installation system
Spout
Fixed spout
Color
Chrome
Temperature
Limitation option for maximum temperature and flow-rate, Adjustable hot water stop (included, retrofittable)
Technical properties
Backflow prevention (EN1717)
AA
Connection size
Ø 8 mm
DN-size (nominal dimension)
DN15
Hot water supply
max. +80°C
Material
Brass
Projection
141 mm
Working pressure
0.5 - 5 bar
Regulations
EN standard
EN 817
Noise class
I (ISO 3822)
