consists of: bath thermostat floor standing, baton hand shower, shower hose, shower holder
projection 190 mm
2 functions
diversion between outlets via diverter knob
T30, ceramic valves 180°
spray type mixer: laminar spray
spray type hand shower: Rain, Mono
maximum flow rate at 3 bar: 19 l/min
flow rate for bath spout at 3 bar: 19 l/min
flow rate of hand shower at 3 bar: 15 l/min
min. operating pressure: 1 bar
max. operating pressure: 10 bar
Safety stop at 40 °C
non-return valve
with automatic resetting
connection dimension: DN15
connection type: basic set
height: 981.0 mm
