2 functions
simultaneous utilization of 2 functions
thermostat cartridge
flow rate upper outlet: 42 l/min
flow rate lower outlet: 40 l/min
maximum flow rate at 3 bar: 42 l/min
min. operating pressure: 1 bar
max. operating pressure: 10 bar
combination of highflow thermostat with shut-off valve and Duo diverter valve for controlling 2 consumers
Safety stop at 40 °C
temperature limitation adjustable
connection dimension: DN20
connection type: basic set
