1 function
thermostat cartridge, ceramic valve 180°
maximum flow rate at 3 bar: 20 l/min
min. operating pressure: 1 bar
max. operating pressure: 10 bar
Safety stop at 40 °C
temperature limitation adjustable
non-return valve
with silencer
centre distance: 150 ± 12 mm
connection dimension: DN15
connection type: S-connections
