consists of: overhead shower, hand shower, single lever shower mixer, shower hose, slider
overhead shower AXOR Citterio
shower head size overhead shower: 180 mm
spray type overhead shower: Rain
spray type hand shower: RainAir, Rain, WhirlAir
flow rate of hand shower at 3 bar: 15 l/min
maximum flow rate for Showerpipe at 3 bar: 18 l/min
minimum flow pressure: 1 bar
max. operating pressure: 10 bar
ball-joint: overhead shower angle adjustable
shower arm length overhead shower: 422 mm
suitable for continuous flow water heaters with an output of 18 kW
mounting type: exposed installation
connection dimension: DN15
connection thread: G ½
centre distance: 150 ± 16 mm
ceramic cartridge
temperature limitation adjustable
2 functions
flow rate Rain spray at 3 bar: 18 l/min
