consists of: thermostatic module, shower holder, baton hand shower, shower hose
3 functions
simultaneous use of several outlets
Select push-button on/off control for 3 functions
depending on volume flow and installation situation approx. 50% flow rate reduction and integrated shut off function
thermostat cartridge, Start/stop valve to operate the functions
flow rate of hand shower at 3 bar: 13 l/min
maximum flow rate at 1 bar: 20 l/min
maximum flow rate at 3 bar: 38 l/min
min. operating pressure: 1 bar
max. operating pressure: 10 bar
Safety stop at 40 °C
temperature limitation adjustable
for shower hoses with a cylindrical nut
connection type: basic set
Thermostat is delivered with buttons handshower, PowderRain, Rain large
