2 functions
simultaneous use of several outlets
comfortable turning on / off of outlets with large Select-paddle, precise temperature control thanks to vertical handle structure and haptic feedback from the thermostat handle
water flow control with stop function
thermostat cartridge, Start/stop valve to operate the functions
maximum flow rate at 1 bar: 12,7 l/min
flow rate upper outlet: 20 l/min
flow rate lower outlet: 20 l/min
maximum flow rate at 3 bar: 22,1 l/min
min. operating pressure: 1 bar
max. operating pressure: 10 bar
flat escutcheon for more space in the shower
escutcheon can be aligned by +/- 3°
easy installation due to pre-assembled function block
handles always at the same height regardless of the installation depth of the basic set
Safety stop at 40 °C
temperature limitation adjustable
the thermostat offers the possibility for thermal disinfection
material button: metal
material handles: metal
connection type: basic set iBox universal 2 (# 01400180)
Select-paddles are delivered with lasered user symbols (Rain large and hand shower)
