shower head size: 120 mm
spray type: Rain
spray angle adjustable in five steps
functions as overhead, shoulder or side shower
maximum flow rate at 3 bar: 5,3 l/min
minimum flow pressure: 1 bar
operating pressure: min. 1 bar/max. 10 bar
connection thread: G ½
in a joined installation (10 mm distance), the basic set no.28486180 must be used
in a freely arranged installation, connection via a G ½ connecting thread is possible
if installed as an overhead shower with several joint modules, the use of installation aid no.28470180 is recommended
suitable for continous flow water heaters
connection dimension: DN15
material: metal
EU taxonomy: max. 6 l/min - Substantial Contribution (SC) possible
flow rate Rain spray at 3 bar: 5,3 l/min
