2 functions
projection: 198 mm
centre distance: 150 ± 16 mm
spray type mixer: normal spray
maximum flow rate at 3 bar: 24 l/min
flow rate for bath spout at 3 bar: 24 l/min
flow rate of hand shower at 3 bar: 18 l/min
ceramic cartridge
temperature limitation adjustable
diverter with automatic resetting
non-return valve
with silencer
suitable for continous flow water heaters
connection dimension: DN15
connection type: S-connections
wall-mounted
min. operating pressure: 1 bar
max. operating pressure: 10 bar
