larger print for greater clarity
with extra long barrier-free handles
projection 172 - 177 mm
2 functions
thermostat cartridge, shut-off/ diverter valve
maximum flow rate at 3 bar: 20 l/min
flow rate for bath spout at 3 bar: 20 l/min
flow rate of hand shower at 3 bar: 16 l/min
min. operating pressure: 1 bar
max. operating pressure: 10 bar
Safety stop at 40 °C
temperature limitation adjustable
non-return valve
with silencer
material handles: metal
connection dimension: DN15
connection type: G ½
centre distance: 150 ± 12 mm
dirt filter included
