1 function
temperature and water flow control
thermostat cartridge
maximum flow rate at 1 bar: 12 l/min
maximum flow rate at 3 bar: 21,3 l/min
min. operating pressure: 1 bar
max. operating pressure: 10 bar
volume control
escutcheon can be aligned by +/- 3°
easy installation due to pre-assembled function block
handles always at the same height regardless of the installation depth of the basic set
Safety stop at 40 °C
temperature limitation adjustable
material handles: metal
connection type: basic set iBox universal 2 (# 01500180)
