projection 193 mm 2 functions CoolContact thermostat: Prevents the housing from heating up, making showering even safer thermostat cartridge, ceramic valve 180° maximum flow rate at 3 bar: 20 l/min flow rate for bath spout at 3 bar: 20 l/min flow rate of hand shower at 3 bar: 12 l/min min. operating pressure: 1 bar max. operating pressure: 10 bar Safety stop at 40 °C temperature limitation adjustable with isolated water conduction non-return valve protected against backflow, according to DIN EN 1717 with silencer material handles: metal shelf made of safety glass surface shelf: white glass connection dimension: DN15 connection type: G ½ centre distance: 150 ± 12 mm dirt filter included in case of installation on existing G ¾ connections, adaptor no.02026000 must be used
