1 function
volume control for 1 function
EcoStop button limits the water consumption to 10 l/min
CoolContact thermostat: Prevents the housing from heating up, making showering even safer
thermostat cartridge, ceramic valve 180°
maximum flow rate at 3 bar: 16,4 l/min
min. operating pressure: 1 bar
max. operating pressure: 10 bar
in case of installation on existing G ¾ connections, adaptor no.02026000 must be used
Safety stop at 40 °C
temperature limitation adjustable
with isolated water conduction
non-return valve
with silencer
shelf made of safety glass
surface shelf: white glass
material handles: metal
centre distance: 150 ± 12 mm
connection dimension: DN15
connection type: S-connections, G ½
dirt filter included
