1 function
temperature and water flow control
Select push-button on/off control for 1 outlet
slider integrated in the shelf
water flow control with stop function
CoolContact thermostat: Prevents the housing from heating up, making showering even safer
thermostat cartridge, Start/stop valve to operate the functions
maximum flow rate at 3 bar: 16,3 l/min
min. operating pressure: 1 bar
max. operating pressure: 10 bar
Safety stop at 40 °C
temperature limitation adjustable
with isolated water conduction
non-return valve
with silencer
suitable for continous flow water heaters
shelf made of plastic
surface shelf: graphite
material handles: plastic
centre distance: 150 ± 12 mm
connection dimension: DN15
connection type: S-connections, G ½
dirt filter included
thermostat is delivered with button hand shower
