battery operation, capable of beeing parameterised by SSC

SCOPE OF DELIVERY:
infrared exposed urinal flush valve with isolating valve
electronic module programmable
battery compartment integrated in fitting
4 x AAA alkaline batteries
6 V solenoid valve in cartridge design with integrated pre-filter
flush pipe O 18 x 193 mm
Urinal inner connector

FIELD OF APPLICATION / TECHNICAL DATA:
flow pressure: 1 to 5 bar
flow volume: 0,3 l/s according to DIN EN 12541
adjustable by means of short range reflex
flow time: 1 - 15 seconds adjustable
sensor range short, medium, long
stagnation flush Out, On 30 s every 24 h after last flush / every 24 h
pre-flush: Out, On 1s
automatic stadium operation: Out, On
odour trap flush: Out, On
expanded setting options with SCHELL Software SSC
flow time: 1 - 15 seconds adjustable
sensor range short, medium, long
stagnation flush time 24 h after last flush, every 24 h (adjustable 1 - 240 h) flush time: 30 s (adjustable 5 - 600 s)
pre-flush: 1 s (adjustabler 5 - 60 s after last use)
automatic stadium programm 1 s/ user (adjustable 20 - 60 s after last use)
odour trap: on 1 h (adjustable 1 - 240 s after las use)
energy - saving mode: active after 1h (adjustment range : out, 1 - 254 h)

DETAILS:
Material:
parts in contact with water conform German drinking water regulation

Test Mark: PA-IX 8952/II, WELL Public
Surface: chrome
Weight: 1.24 kg/pc.
Packaging unit: 1
Dimension: DN 15 G 1/2 ext. thread
