Description
Toilet connection unit including “easy fit” flush plate installation. For installation in a TECEprofil supporting frame. Uni cistern for front actuation: Safety tank made of impact-resistant plastic, tested to EN 14055 Cistern fully pre-assembled and sealed. Cistern connection with outer thread R 1/2" at the side, compatible with quick adapters 10 litre tank volume; 6 litre pre-set standard flush volume, 4.5/7.5/9-litre flush volume can be set at any time; 3-litre partial flush volume for dual-flush system; remaining volume can be used for immediate cleaning flush. insulated against condensation water for TECE flush plates and toilet flush handle can be used as a single or dual-flush cistern “easy fit” flush plate installation Installation tunnel for service opening, can be shortened without tools Low-noise hydraulic filling valve, fitting group 1 according to DIN 4109 Connection unit: 180 or 230 mm crossbeams for toilet mounting Two M 12 retaining bolts and nuts Two adjustable floor supports for floor projections of 0-200 mm Toilet drain bend DN 90 with joint adapter DN 90/100, made of PP Joint adapter also suitable for horizontal installation DN 90 toilet connection set including protective plug Please order separately: Toilet flush plate (see flush plates) Insert chute for cleaning tablets (optional)
