Article title: Villeroy & Boch Architectura Rectangular shower tray, 1400 x 750 x 48 mm, White Alpin
Article number: UDA1475ARA248V-01
Assembly / Assembly type: Surface-mounted, Corner installation|flush-fitting installation|Installation on a base
Assembly instructions: The installation height of the shower tray can be reduced by 30 mm if the Viega outlet fitting art. no. 634 100 is used. Please note: this outlet fitting does not conform to EN 274., From size 1400 x 900, two supports (U82990000) are required.
Drainage rate in l/min: 53
Scope of delivery: 1 x rectangular shower tray , 1 x outlet cover in White Alpine (01), for matt colours, outlet cover in matching matt colours.
Ordering information: Supplied without support frame / base.
Length in mm: 1400
Width in mm: 750
Height in mm: 48
Interior depth: 14
Collection: Architectura
Weight in kg: 19
Material: Acrylic
Colour name : White Alpin
With feet/base: No
Other material: Outlet cover: Acrylic
Other surfaces: Outlet cover: glossy
With bath support: No
Anti-slip class: Anti-slip class A
EAN number: 4051202286798
Model number: UDA1475ARA248V
