Article title: Villeroy & Boch Architectura Rectangular shower tray, 1500 x 1000 x 15 mm, White Alpin
Article number: UDA1510ARA215GV-01
Assembly / Assembly type: Surface-mounted, Corner installation|flush-fitting installation|Installation on a base
Assembly instructions: With MetalRim and an edge height of 15mm, we recommend the use of a composite seal in accordance with ETAG 022 on the floor structure below the shower tray in order to prevent any moisture from penetrating the floor structure., From size 1400 x 900, two supports (U82990000) are required.|The installation height of the shower tray can be reduced by 30 mm if the Viega outlet fitting art. no. 634 100 is used. Please note: this outlet fitting does not conform to EN 274.
Drainage rate in l/min: 53
Scope of delivery: 1 x rectangular shower tray , 1 x outlet cover in White Alpine (01), for matt colours, outlet cover in matching matt colours.
Ordering information: Supplied without support frame / base.
Length in mm: 1500
Width in mm: 1000
Height in mm: 15
Interior depth: 19
Collection: Architectura
Weight in kg: 28
Material: Acrylic
Colour name : White Alpin
With feet/base: No
Other material: Outlet cover: Acrylic
Other surfaces: Outlet cover: glossy
With bath support: No
Anti-slip class: Anti-slip class C
EAN number: 4051202294014
Model number: UDA1510ARA215GV
